Kollmorgen CB06251 servo drive

Kollmorgen CB06251 servo drive

Product Details Introduction

Kollmorgen CB06251 is a digital AC servo driver from the Kollmorgen ServoStar CD/CB series. It is a high-performance, compact servo amplifier designed specifically for precision motion control applications.

Product series: Belonging to the ServoStar CD platform, model CB06251.

Output current: Continuous rated output current of 6A, peak current can reach 18A.

Input power supply: 115-230 VAC single-phase/three-phase wide voltage input, suitable for global industrial power grids.

Control core: Equipped with a 32-bit high-speed DSP processor, the current loop has a high refresh rate and excellent dynamic response.

Control mode: Full mode support - torque, speed, position closed-loop control.

Feedback interface: Supports multiple types of encoders - incremental encoders, Resolvers, EnDat, Hiperface absolute encoders.

Communication bus: EtherCAT, CANopen, SERCOS III, pulse/analog commands are optional.

Safety Function: Integrated STO (Safe Torque Off) function, compliant with PLd/SIL2 safety standards.

Adjustment function: Supports automatic tuning, electronic gear, electronic cam, position/speed/current loop three loop PID adjustment.

Position ring: The update rate of the position ring is 500 µ s (2kHz), with high positioning accuracy.

Braking capability: Built in regenerative braking circuit, can be directly connected to braking resistor, with high energy feedback efficiency.

I/O configuration: 8 digital inputs, 4 digital outputs, all-optical isolation.

Protection function: Full protection against overcurrent, overvoltage, undervoltage, overload, overtemperature, short circuit, and grounding faults.

Environment and Certification: Operating temperature range of 0-45 ° C, certified by international industrial certifications such as UL, CE, EN, etc.

Typical applications: packaging machinery, printing equipment, semiconductor equipment, assembly lines, robots, precision machine tools.

This driver is known for its high power density, high precision, and high stability, providing reliable control for medium power servo shafts. Currently, the market mainly consists of original disassembly and repair parts, which are commonly used spare parts for automation equipment maintenance.
