KNIEL CP15.6311-052-02 Controller Module

KNIEL CP15.6311-052-02 Controller Module

Product Details Introduction

KNIEL CP15.6311-052-02 is an industrial grade high-precision power and control composite module (CP 15.6 series) produced by the German company KNIEL. It is mainly used in DCS, PLC systems, testing equipment, medical and semiconductor equipment, providing stable power supply and signal conditioning/control functions.

Model positioning: CP 15.6 series high-precision power supply+control module, version 052-02, designed according to European industrial standards.

Core function: Integrated with regulated power supply, signal acquisition, logic control, and isolated output, it belongs to the system level power control unit.

Electrical input: Wide voltage DC input of 18-30 VDC (typical 24V), or optional global mains power of 100-240 VAC.

Output specifications: Multi channel stabilized DC output (commonly ± 15V, 5V, 24V), total power of about 60-80W, low ripple and low noise.

I/O configuration: 16 analog inputs (AI), 8 digital inputs (DI), 8 analog outputs (AO), 8 digital outputs (DO).

Signal accuracy: 16 bit AD/DA conversion, with a maximum sampling rate of 1MHz, suitable for high-precision measurement and closed-loop control.

Communication interface: Standard Ethernet (TCP/IP), RS-485 (Modbus RTU), USB, optional CANopen/EtherCAT.

Protection mechanism: Full protection against overvoltage, overcurrent, short circuit, reverse connection, and overheating, automatic recovery and fault alarm.

Hardware design: multi-layer PCB, industrial grade components, fully isolated circuit, strong anti-interference (EMC), high isolation voltage.

Environmental adaptation: Operating temperature range of -25 ° C to+70 ° C, humidity range of 5-95% without condensation, suitable for harsh industrial sites.

Protection level: Panel/port IP20, optional IP65/IP67 sealing for the whole machine, dustproof, moisture-proof, and oil proof.

Size and weight: Compact model 150 × 100 × 30mm, weighing approximately 0.5kg, with dual installation of guide rail/panel.

Application areas: semiconductor equipment, medical instruments, automated testing, industrial robots, ship and rail transit control systems.

Reliability: Long MTBF, fanless design, low power consumption, suitable for 7 × 24-hour continuous operation.

Market status: Discontinued, the market mainly consists of disassembled original parts and repair parts, which are scarce spare parts for high-end equipment maintenance.

This module is centered around high precision, high stability, and multifunctional integration, and is a key component of the "power+control+signal" integration in industrial control systems.
