INDRAMAT 109-0943-4A03-02 Printed Circuit Board

INDRAMAT 109-0943-4A03-02 Printed Circuit Board

Product Details Introduction

INDRAMAT 109-0943-4A03-02 is a servo control/interface printed circuit board for Bosch Rexroth's INDRAMAT series servo control system, providing core signal processing and control functions for servo drive systems. Its specific features are as follows:

The brand belongs to Bosch Rexroth INDRAMAT and is a core control circuit board for servo drives.

Officially positioned as a servo control module/interface board, responsible for servo system signal adjustment and logic control.

Adapt to INDRAMAT DDS, TDM, TDA series servo drives as the core control unit of the system.

Adopting multi-layer PCB high-density design, integrating digital signal processing and analog control circuits.

Support multi axis servo linkage control to achieve precise closed-loop adjustment of position, speed, and torque.

Built in encoder signal interface, compatible with incremental and absolute encoder feedback acquisition.

Equipped with photoelectric isolation circuit, effectively isolating strong electrical interference and improving system stability.

Integrate multiple protections for overcurrent, overvoltage, overheating, and overload to ensure the safety of modules and motors.

Supports industrial bus communication protocols such as PROFIBUS, CANopen, SERCOS, etc.

Adopting a standard European style card insertion design, it can be directly plugged into the servo drive rack slot.

Industrial grade wide temperature operation, working temperature range of * * -10 ° C to+60 ° C * *, suitable for harsh working conditions.

Equipped with self diagnosis and status monitoring functions, providing real-time feedback on operational abnormalities and fault codes.

Compact size, approximately 300 × 150 × 30mm, weighing around 1.2kg, saving installation space.

Mainly used in precision servo scenarios such as CNC machine tools, robots, textile machinery, printing equipment, etc.
