IDEC PF3S-HSC1 Input Module

IDEC PF3S-HSC1 Input Module

Product Details Introduction

IDEC PF3S-HSC1 is a high-speed counting input module specifically designed for Hequan FA-3S series PLCs. It is mainly used for encoder signal acquisition and high-speed pulse detection, and has stable and reliable industrial control performance. Its specific features are as follows:

Suitable for use with IDEC FA-3S series PLC, belonging to a dedicated high-speed counting input module

Supports 4-channel independent high-speed counting, which can meet the simultaneous acquisition of multiple pulse signals

Compatible with single-phase, two-phase, and AB phase orthogonal pulse inputs, with a wide range of applications

The maximum input frequency of a single channel can reach 20kHz, and high-speed signal acquisition does not lose data

Adopting optoelectronic isolation design to effectively enhance anti-interference capability and adapt to industrial environments

Hardware independent counting, not affected by PLC scanning cycle, higher detection accuracy

Equipped with count value power-off hold function, data will not be lost after power-off

Support multiple working modes such as add count, subtract count, and circular count

Comparison threshold can be set to achieve in place triggering and interrupt control

Support external terminal control functions such as start, stop, reset, etc

Equipped with self diagnostic function, capable of real-time monitoring of module operation status

Easy to install, simply plug it into the PLC expansion board

Industrial grade temperature width design, capable of long-term stable operation under harsh working conditions

Mainly used in encoder speed measurement, positioning control, length measurement and other scenarios

 Product imag
