HE693STP104AX processor module

HE693STP104AX processor module

Product Details Introduction

HE693STP104AX processor module product features

HE693STP104AX is a GE Fanuc 90-30 series dedicated stepper motion control module, featuring high-precision positioning, high-speed pulse output, strong adaptability, and stable reliability. It is designed specifically for industrial single axis/multi axis precision motion control scenarios and is widely used in fields such as machine tools, packaging, textiles, and automation production lines.

Original factory exclusive positioning: GE Fanuc genuine product, Series 90-30 PLC system exclusive motion control module, strong system compatibility, seamless integration with the whole machine control.

High speed step control: With a maximum pulse output rate of 245kHz, it supports micro step drive adaptation, precise positioning, smooth operation, and meets the requirements of high-speed precision positioning.

Programmable multi-mode: supports multiple motion modes such as point control, continuous motion, zeroing, and linear interpolation, and is programmable to adapt from simple straight lines to complex multi axis linkage.

Rich peripheral interfaces: can directly connect stepper drivers, limit switches, encoder feedback, support closed-loop position correction, improve positioning accuracy and stability.

Independent axis control design: A single axis independent motion processor that does not occupy the main CPU resources of the PLC, ensuring efficient parallel operation of the main control and motion control in both directions.

Wide temperature industrial grade: working temperature * * -20 ℃~70 ℃ * *, humidity 0%~95%, no condensation, suitable for harsh industrial sites such as high and low temperature, humidity, dust, etc.

Compact standard structure: Complies with the 90-30 series rack specifications, with a compact size and light weight (about 0.2kg), saving cabinet space and supporting dense installation.

Strong anti-interference ability: EMC optimized design, anti electromagnetic interference, anti surge, can operate stably together with frequency converters, servos and other equipment.

High quality hardware selection: military grade PCB, gold-plated contacts, industrial grade chips, anti-oxidation and wear-resistant, with long mechanical and electrical life.

Multiple protection mechanisms: Built in overcurrent, short circuit, overvoltage, and overheating protection to prevent damage to the module and external motors and drivers.

Flexible power supply specifications: Supports 24V DC standard power supply, built-in power filtering and reverse protection, suitable for conventional power sources in industrial sites.

Easy programming debugging: Supports parameterized configuration of GE programming software, supports status monitoring, online modification, fault diagnosis, and reduces debugging difficulty.

Intelligent fault diagnosis: Real time monitoring of pulse output, position deviation, communication status, instant alarm output for abnormalities, and rapid fault location.

International authoritative certification: Through CE, UL, CSA certification, it meets global industrial safety standards and can be exported to various regions around the world.

Full scene coverage: widely used in precision motion control fields such as CNC machine tools, packaging machinery, textile equipment, electronic manufacturing, robots, and automated production lines.

HE693STP104AX, with its core advantages of high speed, precision, stability, and easy integration, has become an ideal choice for achieving precise step motion control in GE 90-30 systems, effectively improving equipment positioning accuracy and production efficiency.
