Product Details Introduction

P0400ZG is a node bus NBI interface module of Schneider Foxboro I/A Series system, responsible for protocol conversion, data transmission, and node management between node bus and system bus, adapting to the distributed I/O networking requirements of process automation sites.

Provide three interfaces: NBI node bus, RS485, and system bus to achieve multi bus interconnection.

Compatible with Foxboro private node bus protocol and Modbus RTU, supporting multi brand field device access.

The communication speed is 2400/4800/9600/19200bps, which can be adjusted by software to meet different on-site bandwidth requirements.

Supports up to 32 distributed nodes for access, supports phased expansion and online configuration.

Single node data transmission delay ≤ 5ms, meeting real-time control requirements.

24VDC (± 10%) power supply, typical power consumption ≤ 5W, energy-saving and suitable for on-site installation.

Built in overvoltage, overcurrent, and electromagnetic interference protection to enhance data transmission security.

Working temperature -40 ℃ to 70 ℃, humidity 0-95% without condensation, suitable for wide temperature and high humidity industrial environments.

Die cast aluminum casing with IP20 protection level, capable of withstanding G3 level vibration and high dust scenarios.

Support online activation, sleep, and fault isolation of nodes to reduce operational complexity.

Node parameters can be flexibly set through dedicated configuration software or Modbus protocol.

Compact structure, seamlessly compatible with I/A Series modules, facilitating system integration.

Equipped with a data verification mechanism to ensure data consistency between nodes and systems.

Support remote node management to reduce on-site wiring costs and construction workload.

Long term stable operation, low failure rate, ensuring continuous production of petrochemicals, electricity, and other industries.

This interface module has stable communication and strong scalability, and is a key component of distributed networking in I/A Series systems, suitable for multi industry process control scenarios.

 Product imag
