ECEA-1616-R24 Electronic Control Module

ECEA-1616-R24 Electronic Control Module

Product Details Introduction

ECEA-1616-R24 is a compact electronic control module from FESTO, belonging to the CPX system component. It provides 16 digital inputs and 16 digital outputs for industrial field signal acquisition and actuator control, and is compatible with distributed IO architecture.

Core specifications and performance

Rated operating voltage: DC 24 V (allowable range 18-30 V)

Input/output channels: 16 channels each, supporting PNP/NPN signals, independent channel diagnosis and status LED

Communication interface: compatible with multiple fieldbuses (such as Profinet, EtherNet/IP, Modbus TCP), with an internal cycle of<1 ms

Protection level: IP65/IP67, working temperature -5 ° C to 50 ° C, storage -20 ° C to 70 ° C, meeting dust and waterproof requirements

Safety and certification: CE, UL, RoHS compliant, supporting ATEX Zone 2 explosion-proof, with diagnostic and fault safety response capabilities for undervoltage, channel faults, etc

Installation and wiring: compatible with CPX system, using spring crimping terminals, supporting rail installation, convenient wiring, and efficient maintenance

Main application areas

Automated assembly line: sensor signal acquisition and cylinder/actuator control for electronic, 3C, and automotive parts workstations

Packaging machinery: Multi channel IO centralized management of filling, sealing, labeling, and palletizing equipment to achieve high-speed linkage

Material handling and transportation: signal transmission and equipment coordination for sorting, transfer, AGV supporting systems

Food and beverage processing: hygiene control of cleaning, filling, and packaging units, suitable for humid and rinsing environments

Medical device manufacturing: clean environment control for assembly, testing, and packaging automation to ensure signal stability

Automotive welding and assembly: Multi actuator control for door assembly, interior installation, and glass lifting testing

Machine tools and fixtures: signal acquisition and action control of pneumatic/hydraulic clamping, positioning, and ejection mechanisms

Environmental protection and water treatment: centralized control and status monitoring of valve groups for dosing, filtration, and backwashing systems

Injection molding and stamping peripherals: IO expansion and linkage of parts picking, shaping, inspection, and packaging automation lines

Laboratory and testing equipment: automated testing bench, small flow rate for sample processing, high-precision signal control

Non standard automation equipment: Distributed IO expansion for customized production lines to meet flexible configuration requirements

Teaching and Research Platform: Teaching and Verification of Pneumatic/Electrical Control Experiment Platforms and Small Production Line Training Devices

This module is compact in size, highly integrated, and has stable communication. It can be quickly integrated into existing control systems and is suitable for centralized control of multiple signals, improving equipment reliability and response speed.
