A20B-2002-0310 Spindle Encoder

A20B-2002-0310 Spindle Encoder

Product Details Introduction

A20B-2002-0310 is a spindle position and speed detection module dedicated to FANUC system, mainly used for closed-loop control of spindle motors, with high stability and strong anti-interference.

Adopting the principle of magneto electric induction, non-contact detection, and long service life

Real time collection of spindle position, speed, and steering signals to ensure control accuracy

Output A, B, Z three-phase pulse signals, compatible with FANUC spindle system

Industrial grade design, resistant to vibration and oil stains, suitable for harsh environments of machine tools

5V DC power supply, differential signal output, strong anti electromagnetic interference capability

Directly installed at the rear end of the spindle motor, with a compact installation structure and accurate positioning

No debugging design, no additional calibration required after replacement

Compatible with mainstream CNC systems such as FANUC 0i, 16i, 18i, 21i, etc

Capable of fault self checking, triggering spindle encoder related alarms in case of abnormalities

Original factory quality, high reliability, suitable for CNC lathes, machining centers and other equipment

As a key feedback component in the FANUC spindle control system, it has stable performance, strong adaptability, and easy maintenance.

 Product imag
