Product Details Introduction

A06B-6077-H106 (also known as PSM-5.5) is a servo power module/spindle driver from FANUC's alpha series in Japan. It provides high-voltage DC bus and servo power for CNC systems, with a focus on high power, high stability, and digital intelligent control.

Type positioning: Alpha series servo power supply/spindle drive module (PSM-5.5)

Input specifications: three-phase 200-230V AC, 50/60Hz, rated current 26A (at 200V)

Output specifications: DC 283-325V, rated power 6.8kW, suitable for medium to high power servo systems

Control core: Built in DSP+HRV3 high response vector control, fast dynamic response, high positioning accuracy

Communication interface: FSSB high-speed serial servo bus, single fiber communication with CNC (0i/16i/18i/21i/30i)

Compatible motors: FANUC α/α i series servo motors, spindle motors

Cooling method: forced air cooling (internal fan+external radiator), efficient heat dissipation

Protection functions: multiple protections such as overcurrent, overvoltage, undervoltage, overheating, short circuit, fan failure, bus abnormality, etc

Common alarms: AL-01 (overcurrent), AL-02 (fan stop), AL-04 (bus undervoltage), AL-06 (input abnormality)

Structural design: Standard rack plug-in card, 90mm wide, metal shielding shell, strong anti-interference

Environmental parameters: Operating temperature -20 ℃~+60 ℃, suitable for harsh industrial environments

Application scenarios: CNC machining centers, CNC lathes, milling machines, FANUC robots, automated production lines

Quality characteristics: Made in Japan, industrial grade reliability, long lifespan, low failure rate

The overall servo power/drive core is high-power, highly reliable, and digital, and is a key component for stable power and precision control in FANUC CNC systems.
