E+H 319083-0200 Printed Circuit Board

E+H 319083-0200 Printed Circuit Board

Product Details Introduction

E+H 319083-0200 is a signal amplification and processing PCB component specifically designed for Endress+Hauser FloWtec series flow meters. It is used for high-precision flow signal acquisition and transmission, and is suitable for industrial process control scenarios.

Original factory specific design, highly compatible with E+H FloWtec flowmeter system.

The core function is to amplify, filter, and shape weak flow signals to enhance measurement stability.

Adopting high-precision analog circuits, with low signal distortion and excellent signal-to-noise ratio.

Industrial grade components, wide temperature stability, suitable for working conditions ranging from -20 ℃ to+60 ℃.

Multi layer PCB layout, strong EMC anti-interference, in line with industrial site standards.

Supports 4-20mA analog output and HART digital communication protocol.

Built in multiple circuit protections for overcurrent, reverse connection, and surge.

Non volatile parameter storage ensures that calibration data is not lost after power failure.

Plug and play, replacement without recalibration, easy maintenance.

Compact size (approximately 7.6 × 10.2cm), standard card slot installation.

Gold plated interface, reliable contact, anti-oxidation, long service life.

Suitable for flow measurement of multiple media such as liquids, gases, and vapors.

Complies with SIL safety standards and enhances process safety.

Original factory quality, high MTBF, and reduced failure rate.

Suitable for harsh industrial environments such as chemical, energy, and water treatment.

The overall flow measurement core signal board is high-precision and highly reliable, and is a key component for the stable operation of E+H flow meters.

 Product imag
