N7K-M148GT-11L port switch module

N7K-M148GT-11L port switch module

Product Details Introduction

N7K-M148GT-11L is a 48 port gigabit electrical port module of the Cisco Nexus 7000 series M1 series, supporting 10/100/1000Mbps adaptive, RJ45 interface, with XL expansion feature, used for core or data center switch expansion.

Product positioning: Nexus 7000 series I/O module, M1 series gigabit electrical interface board, providing high-density 1G copper cable access.

Port specifications: 48 10/100/1000Base-T electrical ports, RJ45 connectors, adaptive speed.

Backplane bandwidth: unidirectional 46 Gbps, full duplex 92 Gbps, distributed across fabric modules.

Software requirements: NX-OS 5.0 or above, compatible with SUP1/SUP2/SUP2E controllers.

Chassis adaptation: Full Nexus 7000 series chassis (10 slots/18 slots, etc.), requiring Fabric-1/2 switching matrix.

Performance indicators: MAC table 128K, Jumbo Frame 9216 bytes, IPv4 routing 1 million, IPv6 routing 350000.

Business features: Supports enterprise level functions such as VLAN, QoS, ACL, link aggregation, VRRP/HSRP, etc.

Physical dimensions: Height 4.4 cm, Width 38.9 cm, Depth 55.6 cm, Weight approximately 7.0 kg.

Power consumption characteristics: The typical power consumption is about 358W, with a maximum of 400W, and it is uniformly powered by the chassis.

Environmental specifications: Operating temperature range of 0-40 ° C (some models support extended temperature zones), industrial grade electromagnetic compatibility.

Installation method: Hot swappable (OIR), occupying one I/O module slot, rail/chassis installation.

Status indication: module status (green/orange/red), port link (green/orange/flashing), ID blue light, for easy operation and maintenance troubleshooting.

Management interface: Supports CLI, XML, SNMP, Cisco DCNM graphic management.

Security features: Supports MAC security, 802.1X authentication, AES encryption, and complies with industry standards such as NEBS.

Typical scenarios: data center server access, enterprise core/aggregation layer gigabit expansion, high-density copper cable access to campus network.

The N7K-M148GT-11L, with its high density, high throughput, and comprehensive enterprise level features, is the core module for expanding gigabit ports on the Nexus 7000 platform, suitable for network scenarios that require high reliability and scalability.

 Product imag
