ECPNC3-1 11150168481 Interface Module

ECPNC3-1 11150168481 Interface Module

Product Details Introduction

ECPNC3-1 11150168481 is an industrial grade counter/position control interface module produced by B&R, a subsidiary of ABB Group. It integrates high-speed pulse acquisition, analog output, and multi protocol communication, and is a key component for position and speed control in automation systems.

Model: ECPNC3-1 (Material Number: 11150168481)

Brand: B&R (B&R)

Type: High speed counter and position control interface module

Core input: 1-channel incremental encoder input, 24 bit high-resolution, input frequency up to 50 kHz

Analog output: 1 channel * * ± 10 V * * analog output, 11 bit resolution

Encoder power supply: supports adjustable output of 5-15 VDC

Communication interface: Dual Ethernet ports (10/100 Mbps), supporting industrial protocols such as Ethernet/IP, PROFINET, Modbus TCP, etc

Processor: Industrial grade ARM9 processor, with a main frequency of 400 MHz, ensuring high-speed computing

Storage configuration: 64 MB SDRAM, 8 MB Data Flash, 64 MB NAND Flash (optional expansion to 512 MB)

Expansion capability: 100 × 2-pin expansion interface, supporting JTAG debugging, UART (RS232/485/422), GPIO, etc

Physical specifications: approximately 140 × 90 × 65 mm, weight 0.5 kg

Working environment: Wide temperature design -40 ° C to+85 ° C, anti vibration, suitable for harsh industrial sites

System compatibility: Seamless adaptation to the full range of Begale PLCs and control systems, supporting Automation Studio programming

In summary, ECPNC3-1 11150168481, with its 50 kHz high-speed pulse acquisition, 24 bit high-precision counting, ± 10 V analog output, and seamless integration with multiple industrial protocols, has become the core interface module for motion control, position monitoring, speed closed-loop, and other scenarios. Its industrial grade hardware design and powerful processing capabilities ensure precise and stable control and data exchange in complex on-site environments, making it a reliable choice for system upgrades and maintenance replacements.

 Product imag
