3ASC25H204 Printed Circuit Board

3ASC25H204 Printed Circuit Board

Product Details Introduction

3ASC25H204 (series: DAPU100) is an industrial grade control/analog signal input printed circuit board (PCB) under ABB, designed specifically for automation control systems, used for high-precision signal acquisition and processing.

Model: 3ASC25H204

Brand: ABB

Series affiliation: DAPU100 series control board

Type: Analog input/control interface board

Channel configuration: 2 universal analog input channels

Support signals: 0-10V/0-20mA/4-20mA/1-5V

Processor: Built in 32-bit microprocessor

Working voltage: 24VDC industrial standard power supply

Communication protocol: Supports industrial buses such as Modbus RTU

Physical dimensions: 70mm × 99mm × 62mm

Weight: Approximately 200g

Working environment: Temperature range of -25 ° C to+55 ° C, vibration resistance of 5g

Application scenario: Used for ABB DCS/PLC systems (such as 800xA, AC800M) to collect temperature, pressure, flow and other transmitter signals

Core applications: equipment control, process monitoring, system signal conditioning, maintenance and replacement

In summary, 3ASC25H204 (DAPU100) is a key analog signal acquisition unit in ABB automation systems. With high precision, industrial grade stability, and strong compatibility, it is widely used in process control, equipment monitoring, and fault repair replacement scenarios, ensuring the accuracy and reliability of system signal acquisition and control.

 Product imag
