Alstom MAE99-04 Isolation Unit Module

Alstom MAE99-04 Isolation Unit Module

Product Details Introduction

Brand and model: Alstom (formerly Converteam) from France, model MAE99-04, officially named 8-channel serial I/F isolation unit.

Core positioning: Industrial DCS/PLC system dedicated signal isolation gateway, realizing electrical isolation of input/output/power supply, blocking interference, and ensuring safety.

Channel specifications: Standard configuration includes 8 independent isolation channels, supporting synchronous isolation transmission of multiple sets of serial signals.

Isolation technology: Adopting a composite scheme of photoelectric and magnetic isolation, with an isolation voltage of ≥ 2500Vrms and strong resistance to common mode interference.

Signal type: Suitable for industrial serial communication signals such as RS-232/RS-485/RS-422, supporting bidirectional transmission.

Communication speed: Supports up to 115.2kbps, meeting the low-speed to medium speed data exchange requirements of industrial sites.

Power supply specification: 24VDC industrial grade power supply, wide voltage range (18-30VDC), compatible with control system standard power supply.

Hardware design: 3U standard card structure, metal shielding shell, anti vibration, anti electromagnetic interference (EMC), suitable for harsh industrial environments.

Physical parameters: weighs approximately 2kg, compact design, supports standard cabinet rail installation.

Status indication: Each channel is equipped with LED status lights, which display real-time communication, fault, and power status for easy on-site diagnosis.

Protection function: Built in overvoltage, overcurrent, surge, ESD protection to ensure the safety of modules and connected devices.

System compatibility: Seamless integration with DCS/PLC systems from brands such as Alstom, GE, Converteam, etc., suitable for power, petrochemical, and rail transit scenarios.

Application scenarios: Signal isolation and transmission in power plants (turbine/generator control), petrochemical plants, rail transit traction systems, and industrial automation production lines.

Reliability: MTBF ≥ 100000 hours, industrial grade components, meeting the continuous operation requirements of critical equipment.

Replacement compatibility: MAE99 series isolation modules of the same series can be directly replaced without the need for system reconfiguration.

In summary, Alstom MAE99-04 is an 8-channel high-performance serial signal isolation unit with core advantages of high isolation voltage, multi-channel independence, industrial grade reliability, and strong anti-interference. It is a key component in industrial control systems that ensures safe signal transmission and suppresses interference.
