KUKA KCP2 00-130-547 teaching pendant

KUKA KCP2 00-130-547 teaching pendant

Product Details Introduction

Brand and model: KUKA KCP2 from Germany, material number 00-130-547, is a handheld teaching terminal specifically designed for KRC2/KRC2 ED05/KRC3 robots.

Core positioning: The core human-machine interaction unit for robot programming, manual teaching, debugging, status monitoring, and safe operation.

System adaptation: Exclusive matching KUKA KRC2, KRC2 ED05, KRC3 control cabinets, compatible with core modules such as MFC3 and CI3.

Communication method: High speed communication with the controller through CAN bus to ensure real-time transmission of instructions and data.

Display configuration: 8-inch color TFT LCD screen, resolution 640 × 480 (VGA), clear and intuitive graphical interface.

Operation input: membrane keyboard+6D mouse combination, supporting precise manual control of multiple axes for robots.

Safety design: Integrated emergency stop button, three-stage enable switch, mode selection knob, in compliance with industrial safety standards.

Power supply specification: 24VDC, rated current of about 0.5A, uniformly powered by the robot control cabinet.

Interface extension: Reserved DIN interface, can be connected to an external MF II keyboard; Support program backup and data transfer.

Protection level: IP54 shell, dustproof and splash proof, suitable for workshop oil and dust environments.

Physical parameters: Weight approximately 3.18kg (7lbs), ergonomic handheld design, not easily fatigued after prolonged operation.

Environmental adaptation: Working temperature from 0 ℃ to+45 ℃, humidity from 5% to 95% without condensation, meeting the requirements of industrial sites.

Function coverage: Supports program editing, coordinate teaching, parameter setting, fault diagnosis, and servo start stop full process control.

Operation mode: Provides manual (T1/T2), automatic (AUT) and other multi-mode switching, suitable for different job scenarios.

Application scenarios: Industrial robot automation production lines for automobile manufacturing, welding, handling, assembly, spraying, etc.

Overall, KCP2 00-130-547 is the standard handheld teaching pendant for KUKA KRC2/KRC3 system, with core advantages of CAN bus communication, 8-inch color screen, 6D precise control, and high safety protection. It is an essential terminal for on-site programming and debugging of industrial robots.

 Product imag
