Product Details Introduction

Brand model: Magnetek MG2-1F-3FE from the United States, belonging to the industrial grade AC-DC switching power supply module of the G2 series.

Core positioning: A highly reliable DC power supply unit for industrial control, communication, and automation equipment, supporting redundancy and parallel expansion.

Input specifications: Wide voltage 100-240V AC, 50/60Hz, compatible with global industrial power grids, input current of approximately 18A.

Output specifications: Typical output 24V DC, current 13-25A, power 300-600W, voltage accuracy better than ± 1%.

Efficiency performance: Conversion efficiency of 85% -90%, low loss, high power density, saving installation space.

Cooling method: natural air cooling or forced air cooling, suitable for different cabinet cooling conditions.

Modular design: supports hot swapping, multi module parallel connection, and can build N+1 redundant or high-power output systems.

Protection function: Built in four fold protection for overvoltage, overcurrent, short circuit, and overheating, with automatic fault recovery.

Status indication: The panel integrates LED, which displays real-time power supply operation and fault status.

Remote monitoring: Optional output status dry contact signal, supports PLC/SCADA remote diagnosis.

Installation form: Standard rack/rail installation, compact structure, convenient for industrial cabinet integration.

Physical parameters: Weight approximately 4.3-4.5kg, metal casing, anti vibration, anti electromagnetic interference.

Environmental adaptation: Working temperature -10 ℃~+70 ℃, humidity 5% -95%, no condensation, meeting the requirements of industrial sites.

Application scenarios: industrial automation, cranes, communication base stations, semiconductor equipment, rail transit control systems.

Alternative model: compatible with MG21F3FE, can be directly replaced to ensure system compatibility.

In summary, MG2-1F-3FE is a 24V industrial grade switching power supply from the Magnetek G2 series. With its core advantages of wide voltage input, high reliability, parallel redundancy, and multiple protections, it is the preferred module for stable power supply of industrial equipment.

 Product imag
