Kongsberg RMP400 603129 Remote Control Module

Kongsberg RMP400 603129 Remote Control Module

Product Details Introduction

Brand and model: Kongsberg RMP400 from Norway, material number 603129, belongs to the maritime remote I/O control module.

Product positioning: Remote I/O controller for ship/maritime automation, used for signal acquisition and control of on-site equipment such as engine rooms and decks.

Communication interface: Standard isolated RS-485 (RBUS), supporting master-slave networking, with a maximum bus length of 1200m.

Power supply specifications: Wide voltage 12-24VDC (18-31.2VDC typical), suitable for marine DC power supply systems.

Input characteristics: compatible with digital/analog inputs, input voltage 0-30VDC, typical input current 5mA, input impedance 20k Ω.

Output characteristics: Digital/analog output compatible, output voltage 0-30VDC, maximum output current 500mA, output impedance 0.1 Ω.

Channel configuration: Multi functional I/O channels, supporting independent configuration of DI/DO/AI/AO software, suitable for various on-site sensors and actuators.

Protective installation: DIN 35mm rail installation, size 124 × 100 × 26mm, main module weighs about 400g, secondary module weighs about 250g.

Status indication: Integrated power, communication, and channel status LEDs for quick on-site diagnosis.

Environmental adaptation: Operating temperature range of -40 ℃ to+85 ℃, resistant to vibration and impact, meeting the strict environmental requirements of maritime affairs.

Electrical isolation: Communication ports are electrically isolated from I/O circuits to enhance system anti-interference and safety.

Fault diagnosis: Supports channel level circuit monitoring, overvoltage/short circuit protection, and automatic fault recovery.

Redundancy capability: Supports dual RBUS redundant communication to ensure continuous operation of the control system.

Certification compliance: Compliant with classification societies such as IACS, DNV-GL, ABS, etc., suitable for global maritime scenarios.

System compatibility: Suitable for integrated automation systems such as Kongsberg K-CHIEF 500/600, and can be directly connected to ship control networks.

In summary, RMP400 603129 is a classic remote I/O module of Kongsberg Maritime Automation, which has the core advantages of wide voltage power supply, multifunctional channels, isolated communication, and class certification. It is widely used for remote monitoring and control of ship engine rooms, pump rooms, decks and other equipment, and is a stable and reliable on-site interface unit for maritime systems.
