2711-T10C10 touch screen panel

2711-T10C10 touch screen panel

Product Details Introduction

Belonging to the PanelView 1000 standard series industrial HMI, a pure touch screen operation terminal, it has been officially discontinued and delisted. It is mainly used for equipment monitoring, command issuance, and alarm processing.

10 inch (10.4-inch diagonal) color TFT display screen, resolution 640 × 480, backlight half life 50000 hours.

Resistive touch screen input, supports single point precise touch, does not require a keyboard, suitable for fast operation scenarios.

The front panel is NEMA 4X/IP65 protected, which can resist oil stains, dust, and water splashes, and is suitable for harsh industrial sites.

Equipped with DeviceNet communication port and RS-232 printer specific interface, it can interface with AB PLC and on-site printing equipment.

Wide range AC power supply 85-264 VAC, 47-63 Hz, recommended independent circuit and fuse protection.

Memory configuration: 1008 KB non-volatile flash memory, 310 KB running memory, suitable for regular image and data storage.

Working temperature 0-55 ℃, storage temperature -25-70 ℃, 5-95% no condensation humidity environment available.

It has industrial grade anti vibration, anti impact, ESD surge protection capabilities, and EMC meets international standards.

Configure the development software as RSView32, and firmware upgrades must follow the official process to prevent device failures.

Support multi language interface switching, convenient for cross-border factories and multi language operators to use.

Embedded installation on the panel, it is strictly prohibited to plug and unplug communication and power lines with power on, and the grounding shielding must comply with DeviceNet specifications.

Through international safety and electromagnetic compatibility certifications such as CE, C-UR-US, and C-Tick, it can be used in the North American and European markets.

The touch screen has a lifespan of up to 1 million clicks, making it suitable for long-term high-frequency industrial operation scenarios.

The recommended alternative model is PanelView Plus 1000 series (such as 2711P-T10C21D8S), and upgrading requires redeveloping the HMI program and adjusting the communication topology.

Overall, 2711-T10C10 is a stable and durable touch screen HMI in traditional industrial control systems, currently in service on a large number of existing devices; When upgrading and migrating, it is essential to focus on two core tasks: communication protocol compatibility and screen program reconstruction.

 Product imag
