1784-KTX Communication Interface Module

1784-KTX Communication Interface Module

Product Details Introduction

1784-KTX Communication Interface Module (ISA Bus)

1784-KTX is a Rockwell Allen Bradley 1784 series ISA bus communication interface card, used for industrial PC/upper computer access to DH+, DH-485 networks, and can also be directly connected to PLC-2/PLC-3 backboards, with remote I/O scanning and PLC communication functions.

Core parameters (plain text, no links)

Model: 1784-KTX/1784-KTX/B, half length ISA card, single channel design.

Bus type: 16 bit ISA/EISA slot, not compatible with 8-bit ISA.

Supporting protocols: DH+, DH-485; Can be directly connected to PLC-2/PLC-3 backboards.

Communication function:

As an active node of DH+/DH-485 network, communicate with PLC-5, SLC 5/04, etc.

Remote I/O scanner, managing remote I/O stations.

Support PLC-PLC communication, online monitoring of programmers, and program upload and download.

Physical interface: 1 15 pin D-sub interface, used to connect DH+/DH-485 network cables.

Power supply: Powered by ISA bus 5V DC, no external power supply required.

Status indication: onboard LED, displaying power, network activity, and fault status.

Size and weight: approximately 160 × 114 × 25mm, weighing approximately 0.25-0.34kg.

Environmental parameters: working temperature 0-60 ° C, storage temperature -40-85 ° C, humidity 5% -95%, no condensation.

Compatible system: Suitable for traditional industrial control systems such as Windows NT/98, requiring KTX Utilities software.

Product status: discontinued, mainly for refurbishment/spare parts in the market, used for maintenance of old PLC-5 and SLC systems.

Application scenarios: Factory automation, process control, monitoring of old production lines, PLC program debugging and data collection.

1784-KTX is a standard interface for connecting ISA bus to DH+network in traditional Rockwell systems, suitable for communication networking between old industrial computers and PLC-5/SLC systems.

1784-KTX Product imag
