1769-ADN adapter module

1769-ADN adapter module

Product Details Introduction

Model 1769-ADN belongs to the Rockwell Compact I/O series DeviceNet adapter module.

Used to connect Compact I/O modules to the DeviceNet fieldbus network.

Supports three communication rates: 125, 250, and 500 kbps.

Can serve as a DeviceNet slave module for data exchange with the master controller.

Compatible with controller platforms such as CompactLogix and MicroLogix 1500.

Supports expansion connections for up to 30 Compact I/O modules.

Using a dip switch to set the DeviceNet node address, with simple configuration.

Equipped with LED status indicator lights, convenient for module and network status diagnosis.

Provide electrical isolation for DeviceNet ports to enhance on-site anti-interference capabilities.

The power supply adopts a dual channel power supply mode of 5V DC for the backplane and 24V DC for the auxiliary.

Supports two installation methods: DIN rail installation and panel installation.

The working temperature range is 0-60 ° C, which meets the environmental requirements of industrial sites.

Compliant with industrial safety and electromagnetic compatibility certification standards such as UL and CE.

Support online replacement and hot plugging operations for easy system maintenance.

Widely used in distributed I/O, small automated production lines, and equipment renovation projects.

The above are the core technologies and application points of the 1769-ADN adapter module. The content is concise and practical, and can be directly used for product introduction and technical selection reference.

1769-ADN  Product imag
