WOODWARD 5466-1035 Controller Module

 WOODWARD  5466-1035 Controller Module

Product Details Introduction

High precision power control: The WOODWARD 5466-1035 controller module focuses on high-precision control and supports precise control of the speed and torque of power equipment such as motors and engines, with a control error of less than 0.2%. It is suitable for high-precision scenarios such as generator sets and industrial transmissions.

Multi signal compatible acquisition: WOODWARD 5466-1035 can be connected to 4-20mA analog, digital, and pulse signals, and can synchronously collect status data of sensors and actuators without the need for additional signal conversion modules, adapting to the collaborative control requirements of multiple types of devices.

Flexible control mode switching: WOODWARD 5466-1035 supports three control modes: manual/automatic/remote. It can be switched with one click through panel buttons or upper computer software to meet the control needs of different scenarios such as on-site operation, automatic operation, and remote monitoring.

Fast command response: The control command response time of WOODWARD 5466-1035 is as low as 2ms, which can quickly handle equipment status changes and adjust output parameters, avoiding control deviations caused by response delays, and is suitable for dynamic control of high-speed operating equipment.

Multiple security protection mechanisms: WOODWARD 5466-1035 has built-in protection functions for over speed, over current, and over temperature. When an abnormal device is detected, it can immediately trigger a shutdown or load reduction command and issue an alarm signal to reduce the risk of equipment damage.

Convenient parameter configuration: WOODWARD 5466-1035 supports parameter settings through matching debugging software or panel display screens. It has built-in parameter templates for commonly used devices, which can quickly complete initialization configuration and reduce debugging time.

Strong anti-interference ability: WOODWARD 5466-1035 adopts optoelectronic isolation technology, and the isolation voltage between the signal channel and the power circuit reaches 1500V DC, which can resist electromagnetic radiation and power grid fluctuations in industrial sites, ensuring stable transmission of control signals.

Wide temperature environment adaptation: The working temperature of WOODWARD 5466-1035 covers -30 ℃ to+70 ℃. The circuit board has been treated with a moisture-proof coating, and can still maintain stable operation in high humidity, dusty mining and chemical scenes.

Support data storage and traceability: WOODWARD 5466-1035 has a built-in storage module that can record device operating parameters, fault information, and operation logs. It can be stored for up to 6 months, making it easy to trace faults and analyze device performance in the future.

Wide device compatibility: WOODWARD 5466-1035 can be adapted to WOODWARD series actuators and sensors, and supports Modbus communication protocol. It can be connected to third-party PLC and SCADA systems and easily integrated into existing industrial control systems.

 WOODWARD  5466-1035 Product imag

WOODWARD   5466-1035 Controller Module
