KEBA E-10-ANALOG-SU Printed Circuit Board

KEBA E-10-ANALOG-SU Printed Circuit Board

Product Details Introduction

KEBA E-10-ANALOG-SU is an analog signal input/output (I/O) expansion PCB module for industrial automation systems. This module is designed for the KEBA control platform to provide high-precision analog acquisition and output capabilities for the main control system. It is widely used in automation scenarios that require analog signal processing, such as temperature control, pressure monitoring, and speed regulation, and is an important component of achieving precision control in the system.

2、 Technical parameters

Model: E-10-ANALOG-SU

Function type: Analog signal input/output circuit board

Input type: Multi channel analog input, supporting 0-10V or 4-20mA (depending on configuration)

Output type: Analog output channel, compatible with standard analog actuators

Accuracy level: High resolution A/D and D/A conversion module, suitable for precision control

Power supply voltage: usually 24V DC

Communication interface: Connected to the main controller through a bus, may support CAN, EtherCAT, or internal expansion interfaces

Installation method: slot type or screw fixed installation

Working environment: Suitable for industrial environments ranging from -10 ° C to+60 ° C, with anti electromagnetic interference design

3、 Application Fields

Temperature controller

Used to receive analog signals from thermocouples, thermal resistors, etc., to achieve precise temperature control adjustment.

Pressure and flow monitoring equipment

Connect pressure sensors/flow meters and other on-site equipment for signal conversion and feedback control.

Servo and Drive System

Provide outputs such as analog speed control and current regulation, suitable for precision motion control equipment.

Injection molding, packaging, and printing machinery

Process input signals from on-site simulated sensors to achieve dynamic control and adjustment.

Product imag
