UNIOP ETOP05EB-DF45 Operation Panel

UNIOP ETOP05EB-DF45 Operation Panel

Product Details Introduction

1、 Product Name

UniOP ETOP05EB-DF45 Operation Panel

2、 Product Overview

ETOP05EB-DF45 is a compact 5.7-inch color touch control panel that integrates graphic display, touch operation, and multiple communication interfaces. It is suitable for local operations such as status display, parameter setting, alarm monitoring, etc. of on-site equipment in industrial automation environments.

3、 Technical parameters (typical configuration)

Project parameter description

Screen size 5.7-inch TFT color LCD

Resolution 320 × 240 pixels (QVGA)

Display color 65536 colors (16 bit)

Touch method: resistive single point touch

Backlight LED backlight, adjustable brightness

ARM series embedded processors

The typical storage configuration is 64MB Flash+32MB RAM (depending on version)

Communication interface RS232, RS485 serial port, some models include Ethernet interface

USB interface USB Host interface (for external data download/upload)

Power input 24V DC (allowable range 18-30V DC)

Protection level: IP65 front panel (embedded installation)

Working temperature: 0 ℃~+50 ℃

Installation method: panel embedded installation with screw clamp fixation

Software supports EXOR Designer or JMobile Studio

4、 Main functional features

Graphic display and control

Can display alarms, real-time variables, historical curves, button controls, animated interfaces, etc

Support custom operation screen and multi language switching

Multi protocol communication capability

Supports protocols such as Modbus RTU/TCP, Siemens S7, Mitsubishi, Allen Bradley, etc

Can communicate with multiple devices simultaneously and support master/slave configuration

Product imag
