UniOP eTOP20B-0050 Operating Interface Module

UniOP eTOP20B-0050 Operating Interface Module

Product Details Introduction

1、 Product Name

UniOP eTOP20B-0050 Operating Interface Module

2、 Product Overview

ETOP20B-0050 is equipped with a 4.3-inch color TFT LCD display screen, using resistive touch technology, designed specifically for space limited and cost sensitive industrial applications. This module supports multiple communication protocols, making it easy to integrate with various PLCs and control systems.

3、 Technical parameters (typical)

Parameter Description

Display screen size 4.3-inch TFT color LCD

Resolution 480 × 272 pixels (WQVGA)

Display color 65536 colors (16 bit color depth)

Touch method: resistive single point touch

ARM Cortex-A series processors

Storage Flash+RAM (capacity depends on version)

Communication interface RS232, RS485, some versions support Ethernet

Power input 24V DC (18~30V)

Protection level front panel IP65

Working temperature: 0 ℃ to+50 ℃

Software support for JMobile Studio and UniOP Designer

4、 Main functions

The graphical interface supports multi screen, multi language, and dynamic display

Supports various industrial communication protocols such as Modbus RTU/TCP, Siemens S7, Allen Bradley, etc

Alarm management, formula control, and data recording functions

Sensitive touch response, supporting custom buttons and interactive operations

Remote program download and maintenance support (some models)

Product imag
