UniOP ETOP512U1P1 operation interface panel

UniOP ETOP512U1P1 operation interface panel

Product Details Introduction

1、 Product Name

UniOP ETOP512U1P1 operation interface panel

2、 Product Overview

ETOP512U1P1 is a high-performance 5.7-inch color TFT LCD touch screen,

Adopting resistive single touch technology and supporting a variety of industrial communication interfaces, it is suitable for local operation and monitoring in embedded control systems.

3、 Technical parameters (typical)

Parameter Description

Display screen size 5.7-inch TFT color LCD

Resolution 320 × 240 pixels (QVGA)

Display color 65536 colors (16 bit color depth)

Touch method: resistive single point touch

Processor ARM Cortex-A8 or similar architecture

Store 128 MB Flash+64 MB RAM

Communication interfaces RS232, RS485, Ethernet USB Host

Power input 24V DC (usually ranging from 18~30V)

Protection level IP65 (panel)

Working temperature: 0 ℃ to+50 ℃

The software development platform supports JMobile Studio programming

4、 Main functions

Graphic interface design supports multi page, multi language, animation, and alarm display

Supports multiple industrial communication protocols, such as Modbus RTU/TCP, Siemens S7, Allen Bradley, etc

Built in data recording, event logging, and recipe management functions

Support remote monitoring and program download

Sturdy structure, adaptable to harsh industrial environments

Product imag
