Uniop ETOP306U201 touch screen panel

Uniop ETOP306U201 touch screen panel

Product Details Introduction

UniOP ETOP306U201 is an industrial grade touch screen human-machine interface (HMI) launched by EXOR International, belonging to the UniOP eTOP series, mainly used for the operation and monitoring of automation equipment.

The following is a detailed explanation without patterns:

1、 Product Name

UniOP ETOP306U201 Touch Screen Panel

2、 Product Overview

ETOP306U201 is a color TFT display touch panel that supports multi touch or resistive single touch (depending on the specific model), suitable for medium to large industrial automation systems, with good display effects and rich communication interfaces.

3、 Technical specifications (typical parameters)

Parameter Description

Display screen type TFT LCD color display screen

Screen size 6.5 inches

Resolution 640 × 480 pixels (VGA)

Display color 65536 colors (16 bit color depth)

Touch mode: resistive single point touch screen

ARM Cortex-A8 processor

Store 128 MB Flash+64 MB RAM

Communication interface RS232, RS485, Ethernet interface

Power input 24V DC (usually ranging from 18~30V)

Operating System Embedded Linux

The protection level of the panel is generally IP65

Working temperature: 0 ℃ to 50 ℃

The software supports JMobile Studio, graphic interface design, and communication protocol development

4、 Main functions

Graphic display: Supports rich graphic interface design, including animation, dynamic charts, and multilingual display.

Touch operation: Supports touch input for easy on-site operation and parameter adjustment.

Communication function: Built in multiple industrial communication protocols, supporting seamless connection with PLC, DCS and other systems.

Alarm and Data Management: Equipped with alarm display, event recording, and data collection functions.

Remote access: Supports remote monitoring and maintenance through Ethernet (depending on specific configuration)

Product imag
