TEL Tokyo Electron REX-B860-CS1 Digital Input Module

TEL Tokyo Electron REX-B860-CS1 Digital Input Module

Product Details Introduction

The TEL Tokyo Electron REX-B860-CS1 Digital Input Module is an industrial grade signal acquisition unit designed specifically for semiconductor manufacturing equipment. It is mainly responsible for receiving and managing digital (DI) signals from on-site sensors, switch devices, interlocking systems, etc. It is one of the important components for real-time monitoring and action judgment in control systems.

1、 Basic Information

Product model: REX-B860-CS1

Product Name: Digital Input Module

Manufacturer: Tokyo Electron Ltd. (TEL)

Module type: Control system I/O submodule

Signal type: Digital input (usually 24V DC or TTL logic)

2、 Main functions

Digital signal acquisition

Receive switch signals from sensors, buttons, limit switches, door control systems, etc;

The collected signals can be used for process start stop control, safety interlocking, equipment feedback, etc.

Status judgment and real-time response

Report the collected ON/OFF status to the main controller (such as E244 series SBC);

Support real-time judgment and triggering of corresponding device actions, such as valve opening and closing, mechanical action linkage, etc.

Signal isolation and protection

The channel has photoelectric isolation to enhance anti-interference ability;

Each channel is equipped with industrial grade protection mechanisms such as input voltage protection and anti reverse connection.

Module communication and bus integration

Connect to TEL control backplane or fieldbus (such as RS485, CAN, TTL parallel bus);

Multiple digital input modules can be combined to construct a large-scale signal acquisition network.

Product imag
