TEL Tokyo Electron BX80-070380-16 Interface Module

TEL Tokyo Electron BX80-070380-16 Interface Module

Product Details Introduction

Product model: BX80-070380-16

Product Name: Interface Module

Manufacturer: Tokyo Electron Ltd. (TEL)

Component Category: Signal Interface and Conversion Module

1、 Product Overview:

The BX80-070380-16 interface module is a key component in TEL semiconductor equipment, responsible for signal conversion, interface connection, and communication coordination between various subsystems within the equipment. This module can support the transmission of various digital and analog signals, and ensure the integrity and reliability of the signals.

2、 Main functions:

Function module description

Signal Conversion: Conversion and Isolation of Digital and Analog Signals

Interface connection provides standard interfaces to achieve interconnection between device modules

Communication coordination supports device bus communication to ensure stable data transmission

Fault protection prevents signal interference and abnormalities from causing equipment failure

Real time monitoring of interface working status through status monitoring, supporting fault alarm

3、 Technical parameters (refer to the specifications of the general interface module):

Project Description

Interface types: IDC connectors, terminal blocks, multi pin plugs, etc

Support signal types TTL/CMOS digital signals, analog voltage signals

Power requirement 5V or 24V DC (depending on specific design)

The communication protocol supports commonly used industrial protocols such as RS-232, RS-485, CAN, etc

Structural form card insertion or modular installation, compatible with TEL equipment rack

Product imag
