Product Details Introduction

Product model: E240-000057-11

Product Name: Controller Cooling Fan Card

Manufacturer: Tokyo Electron Ltd. (TEL)

Component category: Heat dissipation and fan control module

1、 Product Overview:

E240-000057-11 Controller Cooling Fan Card is an electronic module used in TEL semiconductor equipment to control and manage the controller cooling fan. This module monitors the status of the fan, adjusts the fan speed, and achieves effective heat dissipation for the device controller and key electronic components, ensuring long-term stable operation of the equipment.

This fan card integrates fan drive, status detection, and protection functions, and is an important component of the device's thermal management system.

2、 Main functions:

Function module description

Fan drive control adjusts the speed of the cooling fan to adapt to temperature changes

Real time monitoring of fan speed and working status, feedback of abnormal alarms

Overload protection prevents damage to the fan motor due to overload, ensuring safe operation

Interface connection with device main control board and fan motor, supporting signal communication

Fault diagnosis supports the device system to obtain fan fault information for easy maintenance

3、 Technical parameters (typical value estimation):

Project Description

The working voltage is usually 12V or 24V DC

The fan speed range depends on the fan specifications and supports PWM speed regulation or voltage speed regulation

Monitoring signal fan speed sensor signal input (such as Tach signal)

Protection function overcurrent, over temperature, and shutdown alarm

Multi pin connector or terminal block for connecting interfaces
