Product Details Introduction

TEL Tokyo Electron 1181-000544-13 Digital I/O Control Board is a high reliability control module used in semiconductor manufacturing equipment. It is mainly used to collect and output digital signals (switch values), realize various internal action control, status detection, signal relay, and safety interlock logic functions of the equipment.

1、 Basic Information

Product Name: Digital Control Board

Product model: 1181-000544-13

Manufacturer: Tokyo Electron Ltd. (TEL)

Function category: Digital input/output control (DI/DO control)

Applicable systems: TEL Etcher, Coater/Developer, ALD/CVD, handling systems and other types of equipment

2、 Core functions

Digital Input Acquisition (DI)

Receive status feedback signals from various components of the receiving device, such as:

Access control switch status

Pressure sensor triggered

Vacuum pump in place signal

Mechanical limit status, etc

Digital Output Control (DO)

Send control signals to the executing agency, such as:

Open/close the air valve

Start the fan, heater, or relay

Control the action devices such as alarm lights, buzzers, electromagnetic locks, etc

Interlocking and Interlocking Control

Used for inter system security linkage, such as logical judgment in scenarios such as "door not closed → prohibit vacuum start".

High speed logical response

Communicate with the main control system (such as PLC or TEL dedicated controller) to achieve millisecond level response process beat control.
