Siemens 6SN1145-1BA01-0BA1 digital control module

Siemens 6SN1145-1BA01-0BA1 digital control module

Product Details Introduction

Siemens 6SN1145-1BA01-0BA1 is a digital control module in the SIMODRIVE 611 series, used to control and adjust servo drive systems, especially in high-precision equipment such as CNC machines, robots, and automated production lines. This module is typically used to manage and execute instructions and signal processing for servo drives, power modules, and other hardware devices.

Main technical parameters

Series: SIMODRIVE 611

Input voltage: three-phase 380-480V AC

Output voltage: 600V DC (providing bus voltage for the drive system)

Input signal: Supports digital input/output (used for controlling and monitoring servo drive systems)

Communication interface:

PROFIBUS or SERCOS (used for communication with other control systems and drive modules)

High speed and real-time data transmission capability

Compatibility: Fully compatible with SIMODRIVE 611 series servo drive modules

Control mode: digital control, suitable for high-precision servo drive control

Built in features:

Position, speed, torque control

High speed data acquisition and real-time monitoring

Product Features

Efficient digital control

Provide precise position, speed, acceleration, and torque control to ensure the stability and accuracy of the drive system

Real time control and feedback mechanism, suitable for high demand industrial applications

Suitable for closed-loop control systems, providing finer performance tuning

Powerful communication capability

Supports PROFIBUS and SERCOS communication protocols, capable of connecting with different automation control systems

Suitable for complex multi axis control and collaborative work

Modular design

Seamless integration with other SIMODRIVE 611 series components such as power modules, power modules, etc

Support fast installation and maintenance, reducing production line downtime

High reliability and stability

Provide overload protection, short circuit protection and other functions to ensure long-term stable operation

Adapt to challenges such as high temperature, dust, and vibration in industrial environments

Flexible control function

Support multiple servo drive control methods to adapt to different industrial needs

Product imag
