 Introduction

ACS CM-2-B-E-M0-XY Motion Control Module

Introduction: ACS CM-2-B-E-M0-XY is a dual axis XY dedicated drive control integrated module with precise positioning and high integration, suitable for precision platform motion control.

Built in dual axis drive, specifically designed to match XY linear motion platform

High speed servo closed-loop control ensures smooth and vibration free trajectory operation

Supports two axis linear and circular interpolation, with high precision in contour machining

Equipped with digital current loop, fast dynamic response speed

Compatible with multiple types of encoders, suitable for various types of servo motors

Equipped with limit and origin high-speed acquisition input port

Built in multiple hardware protections, automatic shutdown due to overcurrent and overheating

Metal shielding shell, resistant to electromagnetic signal interference in the workshop

Standard EtherCAT bus with low communication latency

Modular compact body, cabinet installation saves space

Equipped with specialized debugging software, with simple parameter settings

Support safe zone restrictions to prevent platform collision damage

Wide voltage power supply, long-term continuous stable operation

Rich digital IO points, compatible with external sensors

Supports both ACSPL+and G-code programming methods

Conclusion: ACS CM-2-B-E-M0-XY is commonly used in laser processing, precision dispensing, and semiconductor testing XY platforms.

Product imag
