AMAT 0190-27709 Backboard Circuit Board

AMAT 0190-27709 Backboard Circuit Board

 Introduction

AMAT 0190-27709 Backboard Circuit Board

Introduction: The AMAT 0190-27709 backplane circuit board is an AMAT semiconductor equipment cabinet interconnection motherboard, which carries power supply and signal transmission for various functional boards.

Multi layer PCB circuit, separate power and signal routing zones

Standard slot position, compatible with CPUs, I/O, and vision boards of the same series

Thickened copper foil wiring for high current transmission and low voltage drop

Equipped with isolation protection, single board faults do not interfere with each other

Built in EMI shielding layer to resist workshop RF interference

Temperature resistant substrate material, not easily deformed during long-term continuous operation

Full board moisture-proof protective coating, suitable for clean workshop environment

Standard bus transmission, low data exchange latency

Multi circuit voltage regulation and diversion, stable output voltage with low ripple

Reserve multiple grounding points for more reliable grounding of the entire machine

Standardization of positioning holes, no need to modify the cabinet for disassembly and replacement

The layout of the circuit is well-organized, and the maintenance of fault points is convenient

Integrated ESD protection to prevent electrostatic breakdown of components

Original factory matching specifications, perfectly compatible with AMAT machine

Precision original factory technology, low rate of open circuit and short circuit faults

Conclusion: AMAT 0190-27709 backplane circuit board has stable interconnection and comprehensive protection, and is the core interconnection carrier of semiconductor equipment cabinets.
