 Introduction

CPICS-6230R power module

Introduction: cPICS-6230R power module is compatible with 6U cPCI industrial control chassis, with a rated power of 300W, providing stable power supply for industrial backplane boards.

100-240V wide AC input, suitable for power supply conditions in various regions

Multiple sets of standard DC outputs to match the power supply requirements of industrial control boards

Built in cooling fan, continuous operation at full load with low temperature rise

Integrated multiple circuit protection for overvoltage, overload, and short circuit

Equipped with EMI filtering to suppress electromagnetic interference clutter in the workshop

Compliant with PICMG industrial standards, supporting hot swappable power supply for board cards

1U compact structure, suitable for 2U rack mounted chassis installation

Small output voltage fluctuation and low ripple ensure stable signal

Good full load conversion efficiency, long-term operation saves more electricity

Standard plug-in interface, disassembly and replacement without complex wiring required

Compatible with 3-slot CompactPCI backplane and 64 bit cards

High temperature resistant components that are not easily aged during long-term operation in the computer room

Equipped with power status monitoring for quick troubleshooting

Metal shielding shell, isolating surrounding RF signal interference

Original factory matching specifications, perfectly compatible with cPICS-6230R chassis

Conclusion: The cPICS-6230R power module has stable power supply and complete protection, and is a core accessory for cPCI industrial control equipment dedicated power supply.

Product imag
