NIDEC 142UDC100RBFCA servo motor

NIDEC 142UDC100RBFCA servo motor

 Introduction

NIDEC 142UDC100RBFCA servo motor product features

beginning

NIDEC 142UDC100RBFCA belongs to Unimotor HD DC brushless servo motor. The 142 base is compatible with semiconductor and precision automation equipment transmission shafts, with fast dynamic response and sufficient torque, and can operate continuously with high precision for a long time.

High torque density permanent magnet winding, with high output torque of the same body and strong short-term overload carrying capacity

Built in high-precision encoder closed-loop feedback, high position acquisition resolution, and minimal repeat positioning error

Low cogging torque rotor design, no vibration during high and low speed operation, smooth and crawling during low speed operation

Original precision long-lasting ball bearings, sealed, dustproof and wear-resistant, greatly extending the service life of the whole machine

Integrated metal shell heat dissipation structure, low temperature rise during full load operation, less likely to trigger overheating protection

Split rotating aviation plug, power line and coding line separated, neat wiring and convenient maintenance

Compatible with the entire range of Nidec drivers, with high parameter matching and no need for complex debugging and adaptation

Standard 142 square flange installation specification, can directly replace motors of the same model, saving time in disassembly and assembly

Built in KTY temperature sensor on the body, real-time monitoring of winding temperature, early warning of high temperature faults

IP65 sealing protection level, dust-proof and spray proof, suitable for use in clean workshops and mildly humid environments

Dynamic balance control for acceleration and deceleration, with minimal start stop impact, to avoid damage from collisions with wafers and precision workpieces

High rigidity rotor structure, stable position under load disturbance, without displacement

Low inductance winding design, fast high-speed commutation response, excellent multi axis synchronous motion synchronization

Built in power-off to maintain electromagnetic brakes, the parking lock shaft is secure, preventing the load from slipping and shifting

Lead free insulation process, compliant with RoHS environmental standards, suitable for high-end production lines and compliant factory delivery of complete machines

ending

The NIDEC 142UDC100RBFCA servo motor combines high dynamics, high precision, and industrial durability, and is a core driving component for precision automation and semiconductor equipment rotary transmission.

Product imag
