AMAT 0100-1200 Printed Circuit Board

AMAT 0100-1200 Printed Circuit Board

Product Details Introduction

AMAT 0100-1200 Printed Circuit Board

Introduction: AMAT 0100-1200 is a dedicated control circuit board for semiconductor equipment, responsible for equipment signal transmission and logic control work.

Original factory matching design, compatible with corresponding thin film deposition equipment

Multi layer precision circuit with low signal transmission loss

Equipped with multiple IO interfaces, connecting various sensor valve bodies

The circuit is isolated and has strong resistance to electromagnetic interference

Integrated voltage stabilization protection circuit to prevent damage to components caused by voltage surges

Onboard fault indicator light, quickly locate circuit abnormalities

High temperature resistant substrate, capable of long-term stable operation in equipment compartments

Surface anti-corrosion coating, resistant to trace corrosive gases in the process

Standard card insertion structure, easy to disassemble and replace operation

Regular circuit layout to reduce signal crosstalk issues

Support 24-hour uninterrupted continuous production operations

Welding point reinforcement process, less prone to detachment under equipment vibration

Reserve expansion points to adapt to various process control requirements

By adhering to the cleanliness production standards in the semiconductor industry

Coordinate the chamber air circuit, temperature control, and vacuum linkage control

Conclusion: AMAT 0100-1200 has strong stability and is a core control spare part for thin film equipment.

Product imag
