ACS CMba2B24N0NEBC240-ORB1 motion control module

ACS CMba2B24N0NEBC240-ORB1 motion control module

Product Details Introduction

Product Features of ACS CMba2B24N0NEBC240-ORB1 Motion Control Module

ACS CMba2B24N0NEBC240-ORB1 is an integrated EtherCAT motion control module specifically designed for semiconductor precision platforms. It integrates servo drive and main control, and is compatible with wafer pre alignment and inspection table equipment.

Built in dual axis servo drive, stable single axis output current, suitable for linear/voice coil motors

20kHz high-speed servo closed-loop sampling, nanometer level positioning jitter, smooth and vibration free motion

As the EtherCAT master station, it can expand control over multiple axes and has high clock synchronization accuracy

Support the integration of multiple encoder signals including orthogonal, sine cosine, and absolute values

Built in advanced gantry decoupling algorithm to eliminate cross axis motion offset errors

S-shaped smooth trajectory planning, high-speed start stop without impact, protecting precision stages

Equipped with vibration suppression algorithm to avoid machine resonance and improve repeat positioning accuracy

Multiple communication interfaces: Ethernet RS232， Connect the upper computer with the equipment PLC

Independent 24V control power supply, power-off retains motion process parameters

Multiple hardware protections: overcurrent, overvoltage, overtemperature, motor short circuit, automatic shutdown

Rich digital/analog IO points, supporting position triggering, vacuum, and gas path linkage

ACSPL+multitasking programming, compatible with G-code and PLC standard programming language

Aluminum alloy integrated heat dissipation shell, low temperature rise under full load for a long time

Modular standard cabinet installation, easy disassembly and replacement

Factory servo parameter calibration, can be adapted to precision motion platforms on the machine

The ACS CMba2B24N0NEBC240-ORB1 motion control module is the core control component for high-precision stages in semiconductor detection, lithography, and coating equipment.
