EDWARDS YT76-Z2-Z20 Controller Unit

EDWARDS YT76-Z2-Z20 Controller Unit

Product Details Introduction

EDWARDS YT76-Z2-Z20 Controller Unit Product Features

EDWARDS YT76-Z2-Z20 is a dedicated control unit for semiconductor molecular pumps, which controls the vacuum pump speed and chamber negative pressure, ensuring stable operation.

Compatible with Edward SCU-1600 series turbo molecular pump

Closed loop speed regulation, maintaining stable vacuum pressure

Wide range universal voltage, workshop voltage fluctuation without downtime

Built in multiple protections, automatic shutdown alarm for overheating and overcurrent

Real time collection of pump body temperature and speed operation data

Built in fault self check, quick identification of fault codes to locate problems

RS485 communication interface, connected to remote control of machine PLC

Power off to save operating parameters, restart without resetting

Low noise heat dissipation duct, not prone to high temperature when fully loaded for a long time

Anti electromagnetic interference circuit, suitable for etching and coating clean workshops

Modular integrated structure, easy disassembly and replacement of cabinets

The status indicator light is intuitive, and abnormal speed can be identified at a glance

Compatible with multiple Edward vacuum gauges, synchronously monitoring vacuum degree

Industrial grade components, continuous mass production with long service life

Standardized wiring terminals, easy wiring maintenance operation

The EDWARDS YT76-Z2-Z20 controller unit is the core control component of semiconductor vacuum systems, ensuring stable vacuum environment in the process chamber.

Product imag
