ADAS STB570 Bus Communication Processing Board

beginning

The ADAS STB570 bus communication processing board is developed for the bus data processing of in vehicle ADAS systems, coordinating bus transmission, analysis, and forwarding to ensure efficient interaction of vehicle sensor data.

Compatible with multiple onboard bus protocols such as CAN and CAN FD for processing

Multiple independent bus channels are processed in parallel without interfering with each other

Equipped with a dedicated communication processing chip, low latency data parsing

Channel optoelectronic isolation design, blocking high and low voltage interference with each other

Built in multi-level EMC filtering to suppress electromagnetic noise inside the car

Integrated protection against overvoltage, overcurrent, static electricity, and reverse connection

Support car 12V wide voltage input, adapt to voltage fluctuation conditions

Split communication status indicator light, quickly locate abnormal channels

Industrial wide temperature device, capable of withstanding high and low temperature environments inside vehicles

Low power circuit design, low heat generation during long-term operation

Lossless signal forwarding, lossless bus transmission rate

Support data caching storage to prevent high-speed data loss

Standard wiring terminals, compatible with various ADAS sensing devices

Power on automatic self check, one click detection of bus line faults

Single channel fault isolation, without interrupting overall communication

ending

The ADAS STB570 bus communication processing board has high computational efficiency and strong anti-interference ability, meeting the requirements of stable communication processing for multiple devices in the vehicle ADAS bus.
