M-3425A Generator Integrated Protection Relay

M-3425A is a digital generator comprehensive protection device that integrates multiple protection functions and is commonly used for safety protection of various generator sets.

Integrated comprehensive protection function, covering multiple types of faults

Equipped with differential protection, it can quickly identify internal faults

Configure frequency and voltage monitoring, respond promptly to abnormalities

Support reverse power and demagnetization protection, suitable for grid connected scenarios

Negative sequence overcurrent protection to deal with three-phase current imbalance

Built in fault recording for easy post analysis and troubleshooting

Storage tape time stamp event record, tracing operational status

Supports multiple communication protocols for convenient remote monitoring

Wide voltage supply, strong adaptability to power grid fluctuations

Dual power options are available to further enhance operational stability

Accurate calculation algorithm, effectively avoiding protection misoperation

Rich switch interface, convenient expansion of control circuit

The working temperature range is large, and it can operate stably even in harsh environments

Clear panel layout, easy local viewing and operation

Modular design, functions can be selected and combined as needed

Overall, M-3425A has complete functions and high reliability, making it the mainstream equipment for relay protection of generator sets.

Product imag
