Atlas Copco PF4000-C-PB-HW power focusing module

Atlas Copco PF4000-C-PB-HW power focusing module

Product Details Introduction

1、 Product Overview

Atlas Copco PF4000-C-PB-HW is a high-performance power control/focusing module integrated with PROFIBUS communication interface (PB) in the PF4000 series. This module is used to drive and control Atlas Copco's intelligent electric tightening tools (such as Tensor ST, ES, ETX series), providing stable power supply, focus control, and tightening process data communication functions, especially suitable for high-end assembly occasions that require industrial bus communication and process control.

2、 Technical parameters (brief)

Power input: 100-240V AC, 50/60Hz

Communication protocol: PROFIBUS-DP (Hardware Integrated Interface)

Supported tool types: Atlas Copco Tensor ST/ES/ETX series, etc

Control mode: torque control/angle control/multi-stage tightening

Integrated functions: data collection, fault diagnosis, program parameter download, real-time monitoring

Installation method: Embedded installation in standard industrial cabinets or production lines

3、 Application Fields

1. Automobile manufacturing

Mainly used for bolted connections of chassis, power system, and interior system in the final assembly workshop

Ensure consistency and safety for assembly processes with high repeatability and mass production

Support integration with PROFIBUS bus for factory automation control system, achieving centralized management

2. Construction Machinery and Rail Transit

High strength threaded connection task for construction machinery frame and transmission system

Precision bolt control of train chassis, electrical box, and high-voltage connectors

3. New energy industry

Torque control of key components in the assembly of power battery packs and electric drive systems

Staged tightening of bolts for battery cooling system

4. Aerospace

High precision fastening tasks for aircraft structural components, cabins, landing gear, etc

Assembly quality control requirements that require full process recording and traceability

5. Manufacturing of household appliances and electronic devices

Precision assembly of electronic products on high-speed production lines

Automated operations with small tightening torque range but high precision requirements

6. Industrial automated assembly line

Cooperate with PLC and robot systems for automatic tightening tasks

Suitable for flexible production lines, unmanned production lines, and intelligent manufacturing systems

Product imag
