TEL Tokyo Electron EC80-0000180-15 Port Hub

TEL Tokyo Electron EC80-0000180-15 Port Hub

Product Details Introduction

The TEL Tokyo Electron EC80-0000180-15 Port Hub is a key communication device used in Tokyo Electron semiconductor equipment to achieve centralized data and signals between multiple devices and modules. It usually serves as a communication hub, supporting the connection, management, and allocation of multiple communication lines, ensuring the orderly and efficient transmission of data flows inside and outside the device.

The following is a detailed introduction to the application areas and functions of the port hub (without graphics):

1、 Basic Information

Product model: EC80-0000180-15

Product Name: Port Hub

Manufacturer: Tokyo Electron Ltd. (TEL)

Equipment type: Communication centralized management module

2、 Main functions

Multi port data aggregation and distribution

Support signal collection and distribution for multiple input/output ports;

Realize data flow between multiple control modules, sensors, and peripheral systems within the device.

Communication Protocol Management

Compatible with internal standard communication protocols of TEL devices;

Supports various interface forms such as industrial Ethernet, serial communication, TTL, etc.

Signal conversion and isolation

Realize interconnection and intercommunication of different signal types;

Provide electrical isolation function to ensure stable signal transmission and prevent interference.

Status monitoring and fault diagnosis

Built in status indicator lights and diagnostic interfaces for real-time monitoring and troubleshooting;

Support link state detection and automatic recovery function.

Product imag
