LR 4220E Chart Recorder

Classify：Industry news |Time：2026-05-12 15:53:18

Product Details Introduction

Dual pen dual channel synchronous recording, capable of monitoring two process parameters simultaneously.

Supports various input signals such as DC voltage, thermocouple (J/K/T), thermistor (Pt100), etc.

High recording accuracy, up to ± 0.2% effective recording range, good linearity.

The pen speed response is fast, with a maximum of about 1600mm/s, accurately capturing transient signals.

The paper feed speed can be adjusted within the range of 10-600mm/min to meet different recording time requirements.

Using 20 meter Z-shaped folding recording paper, the paper replacement cycle is long and maintenance is reduced.

Equipped with pen offset compensation function, effectively improving long-term recording consistency.

Built in alarm function, real-time prompt for exceeding limits, convenient for handling abnormal working conditions.

Supports manual printing and can mark time and key data at any time.

Provide two-level paper speed switching to adapt to monitoring needs at different stages.

Digital filtering is optional (0.1Hz/1Hz/off), with strong anti-interference ability.

The zero range can be calibrated on site and adapted to different working conditions and sensors.

Compact panel installation design (144 × 144 × 280mm), compatible with standard control cabinets.

The paper is driven by a pulse motor, with a speed accuracy of ± 0.1% and stable operation.

Support remote contact control for start stop and speed switching, facilitating system integration.

The LR 4220E chart recorder boasts high precision, multi signal compatibility, stability, and reliability

Product imag

LR 4220E.webp.jpg
