HP 44713A multiplexer

HP 44713A is a high-precision, high-speed FET solid-state multiplexer designed specifically for data acquisition systems.

24 channel differential structure, contactless FET switch

Compatible with HP 3852A/3853A data acquisition host

Maximum scanning speed of 100000 channels per second

The on resistance is about 3.1k Ω, with low offset and low noise

Input bias current ＜ ± 5nA, suitable for weak signals

Bandwidth 200kHz, flatness<1% within 20kHz

Supports up to 100V common mode voltage

Maximum input protection 42V peak

10kHz crosstalk is better than -50dB

Built in filtering to suppress 50/60Hz power frequency interference

Support voltage, thermocouple, strain gauge, and resistance measurement

Support 4-wire high-precision resistance measurement

Multi module cascading expandable channel

No mechanical wear, high long-term stability

It has been discontinued and the market is mainly dominated by second-hand and refurbished products

Overall, HP 44713A is a high-performance and highly reliable multi-channel signal switching module, suitable for high-precision measurement scenarios such as industrial testing and data acquisition.

Product imag
